Architecture

Introduction

EdgeVPN uses libp2p to establish a decentralized, asymmetrically encrypted gossip network which propagates a (symmetrically encrypted) ledger state between nodes.

The ledger is a hash-linked chain of blocks, and it is deliberately minimal:

• There is no proof of work and no consensus protocol. A block is just Index, Timestamp, Storage, Hash and PrevHash, where Hash is a SHA256 over the other four — Index, Timestamp, Storage and PrevHash.
• There is no DAG, CARv2 or GraphSync. The chain holds metadata only — service and file names, machine records, DNS entries, IP allocations, heartbeats — never addressable content.

Because there is no consensus round, “blockchain” here means hash-chained gossiped state, not a distributed ledger with agreement guarantees. Nodes converge because every node keeps re-announcing its own entries and merges what it receives; a node that has just joined, or one that has restarted with an empty chain, is refilled by those re-announcements.

EdgeVPN uses the ledger to store Services UUID, Files UUID, VPN and other metadata (such as DNS records, IP, etc.) and to co-ordinate events between the nodes of the network.

Where the state lives

By default the chain is kept in memory only, and a node that restarts starts from an empty chain and refills it from the network. Starting a node with --ledger-state <dir> swaps the in-memory store for a disk-backed one, so the chain survives restarts. Persisting it is recommended when running trusted networks, so that authorization keys do not have to be re-seeded on every restart.

Ownership of ledger entries

Entries are not anonymous. Every write a node makes is signed with that node’s libp2p private key, and carries the author’s peer ID, a monotonic version, an UpdatedAt timestamp and a signature over a canonical encoding of all of them. Verification needs no key distribution: the public key is recovered from the owner’s peer ID, which embeds it.

When merging an incoming block, a node applies a per-key policy rather than replacing the whole chain:

• Buckets such as machines, services, files, users, DNS, heartbeats and egress are owned. A peer cannot overwrite a live entry that belongs to another peer, replay an older version over a newer one, or forge an entry whose value claims a different peer as its author.
• Buckets that are not registered — including anything you create yourself through the API — are open: the highest version wins and anyone may write them.
• Owned entries have a lease. Most of them are alive only while their owner’s heartbeat is fresh (an eight minute window by default, --ownership-ttl); the heartbeat itself expires on an absolute TTL. The elected leader periodically reaps expired entries by writing signed tombstones, and prunes old tombstones once every node has had time to see them.

This is controlled by --ownership, which defaults to enforce. observe runs the same merge but accepts and logs violations instead of dropping them, and off restores the legacy behaviour: unsigned entries and a whole-block replace where the higher block index wins. All nodes of a network must agree on the mode, because the wire format differs.

For the details, see the authenticated ledger.

What this does and does not protect

The ledger authenticates authorship, not membership. Anything that holds the network token can join the gossip network, announce itself, and write to any open bucket. Ownership stops a member from impersonating or evicting another member; it does not stop a token holder from being a member in the first place.

The VPN data plane does check the ledger: an inbound VPN stream is reset unless the remote peer appears in the machines bucket (or in a configured static peer table), and packets are only routed to a destination IP that resolves to a live machine entry. So a node that is not in the ledger cannot exchange VPN traffic — but since a peer announces its own machine entry, this is a routing table, not an access control list.

Restricting which peers may join is the job of PeerGuardian and peergating, which are opt-in (--peerguard, --peergate); see trusted networks and the security model.

Layers

• Simple (KISS) interface to display network data from the ledger
• asymmetric p2p encryption between peers with libp2p
• rendezvous points dynamically generated from OTP keys
• extra AES symmetric encryption on top, in case the rendezvous point is compromised
• the ledger acts as a sealed encrypted store for the routing table
• connections are created host to host and encrypted asymmetrically

Connection bootstrap

Network is bootstrapped with libp2p and is composed of 3 phases:

In the first phase, nodes do discover each others via DHT and a rendezvous secret which is automatically generated via OTP.

Once peers know about each other a gossip network is established, where the nodes exchange ledger blocks over a p2p e2e encrypted channel. The messages are sealed with a symmetric AES key which is rotated via OTP and shared between the nodes.

At that point a ledger and an API is established between the nodes, and optionally start the VPN binding on the tun/tap device.
